| Mfg. : |
Crawford
Swift |
|
| Age : |
1985 |
|
|
Serial
No. :
|
C5020
|
|
| Type
: |
LRC650CP |
|
| Length
of Bed : |
18'6" |
5,639mm |
| Width
Over Bed Guideways |
3'5" |
1,041mm |
| Max
Length of Roll Admitted |
|
|
| Between
Centres |
10"8" |
3,251mm |
| Max
Length of Roll Admitted |
|
|
| With
Universal Driving Equipment |
8'4" |
2,540mm |
| Max
Dia of Roll |
25" |
635mm |
| Max
Form Change |
4-1/2" |
115mm |
| No
of Speed Ranges |
2 |
|
| Range
of Spindle Speeds |
4-200 RPM
Infinitley Variable |
|
| Range
of Feeds (Inf. Var.) |
|
|
| Longitudinal
and Cross |
0.04"
to 12" / min. |
1 to 300
mm/min. |
| Rapid
Traverse |
118"
/ min. |
3,000 mm/
min. |
| H.P.
of Driving Motor |
40 |
30 KW |
Headstock
Spindle Front
Bearings |
9"
Dia. Bore
Timken Class 3
Bearings Nos.
130902-1314008
1310902-131400 |
229mm |
Headstock
Spindle Rear
Bearings |
6-1/2"
Dia Bore
Light Type
Single Row
Ball Journal |
165mm |
| Net
Weight of Machine |
17 Tons |
17,309kg |
| Max
Weight of Roll |
12 Tons |
12,218kg |
| Section
of Tool |
|
|
| (Box
Type Slides) |
2"
x 2" |
50.8 x 50.8mm |
|
|
